Grabo Slender Seal – For Lifting Long and Narrow Materials
The Slender Seal is the ultimate seal for lifting and handling narrow surfaces like plank tiles, beams, and pipes. At 4 inches wide, it’s designed for precise and secure lifting of heavy or curved materials. Durable and reliable, it’s perfect for both professional contractors and DIY enthusiasts. Upgrade your toolkit with the Slender Seal to enhance efficiency and achieve superior results on any project.
Maximum Capacity lifting is 132 lb (60 kg)
Specifications:
| Black foam seal | |
|---|---|
| Material | SBR rubber foam sponge |
| Color | Black |
| L x W x H | 16.2 x 6.9 x 1.24” (411 x 175 x 31.5 mm) |
| Dimension of seal | 371 x 65 mm |
| Density | 10.6 Lb/cft (170 kg/m^3) |
| Hardness, Shore C | 10_2 |
| Tearing pressure | 1800 Psi (126 kg/cm^2) |
| Compression to 25% size at | 8.5 Psi (6000 kg/m^2) |
| Lifetime (Compressions till performance reduction). | ~900 |
| Water Absorption, % | <=5 |
| Shrinkage at 160F (70C) for 24 hrs, % | <=20 |
| Recommended Storage Temperature | Room temperature |
| Red seal | |
| Material | Silicon Foam |
| Color | Red |
| L x W x H | 16.2 x 6.9 x 1.24” (411 x 175 x 31.5 mm) |
| Density | 40.5 Lb/cft (650 kg/m^3) |
| Hardness, Shore C | 55_5 |
| Water Absorption, % | |
| Recommended Storage Temperature | Room temperature |
| Full seal | |
| Features | Combined seal on plastic frame Slender profile |
Lifting Capacity:
 | Perpendicular Hold Z | Parallel Hold X | Parallel Hold Y | |||
|---|---|---|---|---|---|---|
| Maximum value | Safe value（50%) | Maximum value | Safe value（50%) | Maximum value | Safe value（50%) | |
| Glass | 264 lbs (120kg) | 132 lbs (60kg) | 110 lbs (50kg) | 55 lbs (25kg) | 220 lbs (100kg) | 110 lbs (50kg) |
| Metal | 242 lbs (110kg) | 121 lbs (55kg) | 110 lbs (50kg) | 55 lbs (25kg) | 220 lbs (100kg) | 110 lbs (50kg) |
| Wood | 187 lbs (85kg) | 94 lbs (43kg ) | 66 lbs (30kg) | 33 lbs (15kg) | 176 lbs (80kg) | 88 lbs (40kg) |
| Rough Concrete | 264 lbs (120kg) | 132 lbs (60kg) | 110 lbs (50kg) | 55 lbs (25kg) | 220 lbs (100kg) | 110 lbs (50kg) |
